Objects of this class are used to convert vertex data from a Geom into a format suitable for passing to the rendering backend. More...
#include "geomMunger.h"
Public Member Functions | |
| GeomMunger (GraphicsStateGuardianBase *gsg) | |
| GeomMunger (const GeomMunger ©) | |
| int | compare_to (const GeomMunger &other) const |
| CPT (GeomVertexFormat) munge_format(const GeomVertexFormat *format | |
| CPT (GeomVertexData) munge_data(const GeomVertexData *data) const | |
| CPT (GeomVertexFormat) premunge_format(const GeomVertexFormat *format) const | |
| CPT (GeomVertexData) premunge_data(const GeomVertexData *data) const | |
| virtual TypeHandle | force_init_type () |
| int | geom_compare_to (const GeomMunger &other) const |
| GraphicsStateGuardianBase * | get_gsg () const |
| Returns a pointer to the GSG that created this munger. More... | |
| virtual TypeHandle | get_type () const |
| bool | is_registered () const |
| Returns true if this munger has been registered, false if it has not. More... | |
| bool | munge_geom (CPT(Geom) &geom, CPT(GeomVertexData) &data, bool force, Thread *current_thread) |
| Applies the indicated munger to the geom and its data, and returns a (possibly different) geom and data, according to the munger's whim. More... | |
| void | operator= (const GeomMunger ©) |
| void | premunge_geom (CPT(Geom) &geom, CPT(GeomVertexData) &data) const |
| void | remove_data (const GeomVertexData *data) |
| Removes a prepared GeomVertexData from the cache. More... | |
 Public Member Functions inherited from TypedReferenceCount | |
| TypedReferenceCount (const TypedReferenceCount ©) | |
| void | operator= (const TypedReferenceCount ©) |
| Public Member Functions inherited from TypedObject | |
| TypedObject (const TypedObject ©)=default | |
| TypedObject * | as_typed_object () |
| Returns the object, upcast (if necessary) to a TypedObject pointer. More... | |
| const TypedObject * | as_typed_object () const |
| Returns the object, upcast (if necessary) to a TypedObject pointer. More... | |
| int | get_best_parent_from_Set (const std::set< int > &) const |
| int | get_type_index () const |
| Returns the internal index number associated with this object's TypeHandle, a unique number for each different type. More... | |
| bool | is_exact_type (TypeHandle handle) const |
| Returns true if the current object is the indicated type exactly. More... | |
| bool | is_of_type (TypeHandle handle) const |
| Returns true if the current object is or derives from the indicated type. More... | |
| TypedObject & | operator= (const TypedObject ©)=default |
| Public Member Functions inherited from ReferenceCount | |
| int | get_ref_count () const |
| WeakReferenceList * | get_weak_list () const |
| Returns the WeakReferenceList associated with this ReferenceCount object. More... | |
| bool | has_weak_list () const |
| Returns true if this particular ReferenceCount object has a WeakReferenceList created, false otherwise. More... | |
| void | local_object () |
| This function should be called, once, immediately after creating a new instance of some ReferenceCount-derived object on the stack. More... | |
| void | ref () const |
| Explicitly increments the reference count. More... | |
| bool | ref_if_nonzero () const |
| Atomically increases the reference count of this object if it is not zero. More... | |
| bool | test_ref_count_integrity () const |
| Does some easy checks to make sure that the reference count isn't completely bogus. More... | |
| bool | test_ref_count_nonzero () const |
| Does some easy checks to make sure that the reference count isn't zero, or completely bogus. More... | |
| virtual bool | unref () const |
| Explicitly decrements the reference count. More... | |
| WeakReferenceList * | weak_ref () |
| Adds the indicated PointerToVoid as a weak reference to this object. More... | |
| void | weak_unref () |
| Removes the indicated PointerToVoid as a weak reference to this object. More... | |
Static Public Member Functions | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| static | PT (GeomMunger) register_munger(GeomMunger *munger |
| static void | unregister_mungers_for_gsg (GraphicsStateGuardianBase *gsg) |
| Removes all the mungers from the registry that are associated with the indicated GSG. More... | |
| Static Public Member Functions inherited from TypedReferenceCount | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| Static Public Member Functions inherited from TypedObject | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
| This function is declared non-inline to work around a compiler bug in g++ 2.96. More... | |
| Static Public Member Functions inherited from ReferenceCount | |
| static TypeHandle | get_class_type () |
| static void | init_type () |
Public Attributes | |
| const GeomVertexAnimationSpec &animation | const |
| static Thread * | current_thread |
| Public Attributes inherited from TypedObject | |
| get_type | |
| Public Attributes inherited from ReferenceCount | |
| get_ref_count | |
| Returns the current reference count. More... | |
Friends | |
| class | Geom |
| class | GeomCacheManager |
Additional Inherited Members | |
| Public Types inherited from GeomEnums | |
| enum | AnimationType { AT_none, AT_panda, AT_hardware } |
| enum | Contents { C_other, C_point, C_clip_point, C_vector, C_texcoord, C_color, C_index, C_morph_delta, C_matrix, C_normal } |
| enum | GeomRendering { GR_indexed_point = 0x00001, GR_indexed_other = 0x10000, GR_indexed_bits = 0x10001, GR_point = 0x00002, GR_point_uniform_size = 0x00004, GR_per_point_size = 0x00008, GR_point_perspective = 0x00010, GR_point_aspect_ratio = 0x00020, GR_point_scale = 0x00040, GR_point_rotate = 0x00080, GR_point_sprite = 0x00100, GR_point_sprite_tex_matrix = 0x00200, GR_point_bits = 0x003fe, GR_triangle_strip = 0x00400, GR_triangle_fan = 0x00800, GR_line_strip = 0x01000, GR_composite_bits = 0x01c00, GR_strip_cut_index = 0x20000, GR_flat_first_vertex = 0x02000, GR_flat_last_vertex = 0x04000, GR_shade_model_bits = 0x06000, GR_render_mode_wireframe = 0x40000, GR_render_mode_point = 0x80000, GR_adjacency = 0x100000 } |
| enum | NumericType { NT_uint8, NT_uint16, NT_uint32, NT_packed_dcba, NT_packed_dabc, NT_float32, NT_float64, NT_stdfloat, NT_int8, NT_int16, NT_int32, NT_packed_ufloat } |
| enum | PrimitiveType { PT_none, PT_polygons, PT_lines, PT_points, PT_patches } |
| enum | ShadeModel { SM_uniform, SM_smooth, SM_flat_first_vertex, SM_flat_last_vertex } |
| enum | UsageHint { UH_client, UH_stream, UH_dynamic, UH_static, UH_unspecified } |
Detailed Description
Objects of this class are used to convert vertex data from a Geom into a format suitable for passing to the rendering backend.
Typically, the rendering backend will create a specialization of this class to handle its particular needs (e.g. DXGeomMunger). This class is necessary because DirectX and OpenGL have somewhat different requirements for vertex format.
This also performs runtime application of state changes to the vertex data; for instance, by scaling all of the color values in response to a ColorScaleAttrib.
A GeomMunger must be registered before it can be used, and once registered, the object is constant and cannot be changed. All registered GeomMungers that perform the same operation will have the same pointer.
Definition at line 50 of file geomMunger.h.
Member Function Documentation
◆ get_gsg()
|
inline |
Returns a pointer to the GSG that created this munger.
Definition at line 18 of file geomMunger.I.
Referenced by CPT(), and StandardMunger::get_gsg().
◆ is_registered()
|
inline |
Returns true if this munger has been registered, false if it has not.
It may not be used for a Geom until it has been registered, but once registered, it may no longer be modified.
Definition at line 28 of file geomMunger.I.
Referenced by PT().
◆ munge_geom()
| bool GeomMunger::munge_geom | ( | CPT(Geom) & | geom, |
| CPT(GeomVertexData) & | data, | ||
| bool | force, | ||
| Thread * | current_thread | ||
| ) |
Applies the indicated munger to the geom and its data, and returns a (possibly different) geom and data, according to the munger's whim.
The assumption is that for a particular geom and a particular munger, the result will always be the same; so this result may be cached.
If force is false, this may do nothing and return false if the vertex data is nonresident. If force is true, this will always return true, but it may have to block while the vertex data is paged in.
Definition at line 95 of file geomMunger.cxx.
◆ remove_data()
| void GeomMunger::remove_data | ( | const GeomVertexData * | data | ) |
Removes a prepared GeomVertexData from the cache.
Definition at line 76 of file geomMunger.cxx.
◆ unregister_mungers_for_gsg()
|
inlinestatic |
Removes all the mungers from the registry that are associated with the indicated GSG.
Definition at line 52 of file geomMunger.I.
The documentation for this class was generated from the following files:
- panda/src/gobj/geomMunger.h
- panda/src/gobj/geomMunger.cxx
- panda/src/gobj/geomMunger.I
